Specification

Laser wavelength

1.00-1.10um

Laser Type

Fiber laser(TEM00, M2<2)

Laser output power

20W

Modulation frequency

20 ~ 100 kHz

Max. Marking speed

7000 mm/s, (according to the material)

Marking area

70*70 mm, 110*1001mm, 160*160mm optinal

Repeatability

0.02 mm

Positioning accuracy

0.02 mm

Marking depth

0.01 ~ 0.2mm(according to the material)

Beam Diameter

10um

Cooling

air cooled

Z Axis

Motorized

Rotation

Can be rotated automatically

Power supply

single phase 220V AC 500VA 50/60Hz

Construction

 Components

Ø High quality laser source

Ø Visible red beam pilot laser

Ø POWER SUPPLY

Ø High speed Galvo Head and F-θ Lens

Ø Control CARD

Ø Special marking software

Ø Computer(LCD)

Brief Introduction

Equipment performance

The machine adopts originally imported fiber laser and imported speedy Gavol scanning system. High quality of light beam, long using time, stable equipment performance exempts maintenance. It is speedy, and precious. Marking has non-touched process, permanent effect, humanized operation, and stable running. The proprietary control software may compatible software output of AutoCAD, CorelDraw, Photoshop, etc. It can realized automatic edition and correction of characters, signs, graphs, images, bar codes, two-dimensional codes, automatically increased serial numbers. It can support various file formats like PLT, PCX, DXP, BMP, JPG, and so on. It may use TIF fonts directly. 24-hour non-stop running makes it meet the demand of massive on-line and off-line industrialized production.

Application

The machine is widely applied in electronic component, the communication, the spare parts of automobiles and motorcycles, instrument and meter, aerospace, war products, hardware and machinery, measuring and cutting tools, sanitary equipment, medication, food and beverage, cosmetics, drugs packing, medical appliance, solar energy, handicraft and so on. It is suitable to mark on all kinds of metal and partial nonmetallic material.
